Rincian Produk
Tempat asal: Cina
Nama merek: FRIENDSHIP MACHINERY
Sertifikasi: CE, ISO
Nomor model: Seri GSJ
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 1
Kemasan rincian: standar Kemasan
Waktu pengiriman: 30 hari kerja
Syarat-syarat pembayaran: L/C, T/T
Mengontrol cara: |
NC / CNC |
Benda kerja yang cocok: |
Baja karbon / baja tahan karat |
Kekuasaan: |
Hidrolik |
Sistem: |
Estun / Delem |
Garansi: |
1 tahun |
Kompensasi: |
Opsi |
Mengontrol cara: |
NC / CNC |
Benda kerja yang cocok: |
Baja karbon / baja tahan karat |
Kekuasaan: |
Hidrolik |
Sistem: |
Estun / Delem |
Garansi: |
1 tahun |
Kompensasi: |
Opsi |
| Spesifikasi | Kekuatan nominal | Panjang meja kerja | Jarak antar kolom | Kedalaman tenggorokan | Maks. geser slide | Maks. menutup tinggi | Waktu perjalanan | Tenaga motor utama | Maks. tekanan hidrolik | Dimensi garis besar |
| WC67Y | KN | mm | mm | mm | mm | mm | Mm-1 | KW | MPa | mm |
| 30T-1600 | 300 | 1600 | 1240 | 150 | 85 | 180 | 20 | 3 | 16 | 1620x800x1600 |
| 30T-2000 | 300 | 2000 | 1640 | 150 | 85 | 180 | 20 | 3 | 16 | 2020x800x1600 |
| 40T-2500 | 400 | 2500 | 2040 | 200 | 110 | 340 | 10 | 4 | 20.5 | 2500x1300x2000 |
| 50T-2500 | 500 | 2500 | 2040 | 200 | 110 | 340 | 10 | 4 | 20.5 | 2500x1500x2120 |
| 63T-2500 | 630 | 2500 | 2040 | 200 | 110 | 360 | 12 | 5.5 | 20.5 | 2500x1500x2250 |
| 63T-3200 | 630 | 3200 | 2500 | 200 | 110 | 360 | 12 | 5.5 | 20.5 | 3200x1500x2300 |
| 100T-2500 | 1000 | 2500 | 1900 | 320 | 120 | 370 | 15 | 7.5 | 25 | 2500x1600x2400 |
| 100T-3200 | 1000 | 3200 | 2600 | 320 | 120 | 370 | 15 | 7.5 | 25 | 3200x1600x2500 |
| 100T-4000 | 1000 | 4000 | 3200 | 320 | 120 | 370 | 15 | 7.5 | 25 | 4000x1600x2500 |
| 125T-2500 | 1250 | 2500 | 1900 | 320 | 120 | 370 | 12 | 7.5 | 25 | 2500x1600x2400 |
| 125T-3200 | 1250 | 3200 | 2600 | 320 | 120 | 370 | 12 | 7.5 | 25 | 3200x1600x2600 |
| 125T-4000 | 1250 | 4000 | 3200 | 320 | 120 | 370 | 12 | 7.5 | 25 | 4000x1600x2600 |
| 160T-2500 | 1600 | 2500 | 1850 | 320 | 200 | 460 | 10 | 11 | 25 | 2500x1800x2590 |
| 160T-3200 | 1600 | 3200 | 2460 | 320 | 200 | 460 | 10 | 11 | 25 | 3200x1800x2690 |
| 160T-4000 | 1600 | 4000 | 3260 | 320 | 200 | 460 | 10 | 11 | 25 | 4000x1800x2690 |
| 160T-6000 | 1600 | 6000 | 4800 | 320 | 200 | 460 | 10 | 11 | 25 | 6000x1900x3200 |
| 200T-3200 | 2000 | 3200 | 2460 | 320 | 200 | 460 | 10 | 15 | 25 | 3300x1800x2690 |
| 200T-4000 | 2000 | 4000 | 3260 | 320 | 200 | 460 | 10 | 15 | 25 | 4000x1800x2690 |
| 200T-6000 | 2000 | 6000 | 4800 | 320 | 200 | 460 | 10 | 15 | 25 | 6000x2070x3300 |
| 250T-3200 | 2500 | 3200 | 2400 | 400 | 250 | 530 | 10 | 18.5 | 20.5 | 3300x2140x3250 |
| 250T-4000 | 2500 | 4000 | 3200 | 400 | 250 | 530 | 10 | 18.5 | 20.5 | 4000x2140x3250 |
| 250T-6000 | 2500 | 6000 | 4800 | 400 | 250 | 530 | 10 | 18.5 | 20.5 | 6000x2140x3400 |
