Automated Assembling Straightening H Beam Welding Machine Low Noise
Cahaya Tinggi | h mesin berkas perakitan,Terendam Peralatan Arc Welding |
---|
ZHJ1800 H beam 3 in 1 machine, Assembly/ weld/ straighten in one machine
● Work-piece web height: 200-1800mm
● Work-piece web thickness: 6-20mm
● Work-piece flange width: 150-800mm
● Work-piece flange thickness: 6-40mm (thickness can be straightened 6-25mm)
● Work-piece length: 400015000mm
● Work-piece material: Q235 (tensile strength ≤235MPa)
● Welding joints height: 4-8mm
● Welding speed adjustable range: 0.2-2m/min (choose the suitable welding technology and speed according to the welding joints height, welding wire diameter)
● Input conveyor: 2600mm/section, 3 sections conveyors (one is drive conveyor, which is driven by chain)
● Output conveyor: 1 section of double rollers lifting conveyor, 3 sections of single roller lifting conveyor, 3 sections of double roller idler conveyor (total length is about 11.5m)
● Pull-rod system: 2 groups (one driving and one idler)
● Total power: main frame is about 17KW, SAW welding machine powere is about 100KW×2 sets
● Voltage: 3P, AC 380V, 50HZ
Matching table between web height and flange width | ||||
Web height (mm) | 200-295 | 295-390 | 390-530 | 530-2000 |
Flange width (mm) | 150-275 | 150-460 | 150-650 | 150-800 |
