Rincian Produk
Place of Origin: China
Nama merek: Friendship Machinery
Sertifikasi: CE, ISO
Model Number: FSM-PB
Ketentuan Pembayaran & Pengiriman
Minimum Order Quantity: 1
Packaging Details: wooden pallet
Delivery Time: 20 working days
Supply Ability: 30 sets per month
Model: |
WC67Y-600T / 6000 |
Pengontrol: |
E21 |
Kekuatan lembaran baja yang ditekuk: |
450N / mm2 |
Diemensi keseluruhan: |
6100 × 2500 × 4200 |
Total berat: |
52000kgs |
Tekanan kerja sistem hidrolik: |
26MPa |
Model: |
WC67Y-600T / 6000 |
Pengontrol: |
E21 |
Kekuatan lembaran baja yang ditekuk: |
450N / mm2 |
Diemensi keseluruhan: |
6100 × 2500 × 4200 |
Total berat: |
52000kgs |
Tekanan kerja sistem hidrolik: |
26MPa |
1. Overview
● The device adopts all steel-welded construction, and vibratory stress relief. Thus the device with good rigidity and high strength, to permit high accuracy.
● The whole frame with good rigidity, work is stable, safety and reliable, easy to operate.
● To adopt stress theory to control the deformation of structural parts effectively, so can to get satisfied work-piece.
● The workbench adopts bottom cylinder to do deflection compensation, to higher work accuracy.
● Controller: E21 from ESTUN is a cnc controller specialized in torsion axis synchronous press brake machine.
2. Technical parameters
| Model | Units | WC67Y-600T/6000 | |
| Controller | / | E21 | |
| The bended steel sheet strength | N/mm2 | 450 | |
| Nominal pressure | kN | 6000 | |
| Worktable length | mm | 6000 | |
| The distance between uprights | mm | 4850 | |
| Throat depth | mm | 400 | |
| Ram stroke | mm | 300 | |
| Max opening height between worktable and ram | mm | 590 | |
| Gear pump | Model | / | CP2-100-P-10R |
| Flow | L/min | 100 | |
| Pressure | Mpa | 31.5 | |
| Ram speed | Unloaded | mm/s | 50 |
| Work | mm/s | 6 | |
| Return | mm/s | 60 | |
| Working Pressure of hydraulic system | Mpa | 26 | |
| Main motor Power | kW | 45 | |
| Electrical system | V/Hz | 3 phase,380V, 50HZ | |
| Total weight | kgs | 52000 | |
| Overall diemension | mm | 6100×2500×4200 | |
